From lighting and locks to windows and wipers, the body control module (BCM) is responsible for a myriad of vehicle features. It’s the reason these systems receive power, respond to user inputs, and communicate with other electronic control units (ECUs).
Whether you’re an auto enthusiast, repair shop owner, or aspiring bench programming specialist, it’s worth understanding exactly what a body control module does, how it works, and why it’s essential. To help you get up to speed, BenchForce, a leader in automotive bench programming, created this BCM overview.
What Is An Electronic Control Unit (ECU)?
Before getting into the nuts and bolts of a BCM, let’s look at an ECU. An ECU is a small, specialized computer found in vehicles made after the late 1960s. The term “ECU” is broad, denoting any specialized computer module controlling a specific part of a vehicle, be it the engine, transmission, brakes, or, of course, the body. While each module’s core purpose can vary, all ECUs rely on similar principles:
- Data Input: Sensors gather real-time information, such as temperature, pressure, and speed, and send these signals to the ECU.
- Processing & Logic: The ECU’s software (firmware or calibration) interprets data, runs calculations or control algorithms, and decides how to respond.
- Output Commands: Based on its internal logic, the ECU controls actuators (e.g., injectors, valves, motors, lights) by sending precise electrical signals.
ECUs share data through communication networks (e.g., CAN bus, LIN Bus, MOST Bus) to:
- Ensure the vehicle’s systems are working properly
- Enhance performance Improve safety
- Coordinate control
- Diagnosis and troubleshoot
Under the umbrella term “ECU,” there are a host of specific modules, such as the engine control module (ECM), transmission control module (TCM), and Body Control Module (BCM).
What Is a Body Control Module (BCM)?
A body control module (BCM) is an electronic control unit (ECU) that manages and coordinates non-engine-related systems in a vehicle. By and large, the BCM focuses on comfort, convenience, and safety features, such as:
|
|
Why Would You Reprogram a BCM?
There are a few different reasons a person might reprogram a BCM. However, unlike reprogramming an ECM or a TCM for performance, updating the BCM is often about convenience, comfort, and safety. For instance, a bench programming specialist may be reprogramming a BCM to:
- Add a remote start feature
- Change keyless entry settings
- Customize lighting
- Enable/disable daytime running lights (DRLs)
- Include seat memory or driver profile settings
- Update security or alarm
When reprogramming is not about upgrades, it’s about software fixes, addressing recalls, and diagnosing issues. Original equipment manufacturers (OEMs) may release updates to address bugs, improve functionality, or comply with regulatory changes. For instance, an OEM might reprogram a BCM to fix:
- Battery drain or “no sleep” issues
- False or random security triggers
- Feature malfunctions
- Incorrect regional settings
- Intermittent electrical behaviors
- Wiper and accessory control problems
Why Reprogram On The Bench?
Bench programming unlocks many possibilities for vehicle owners and technicians. Essentially, a person can configure vehicle settings, troubleshoot electrical faults, or perform software updates without needing the entire car present. In fact, you can program without the vehicle at all and just use the module. Getting rid of an aging vehicle’s problematic wiring can even prevent bricking a module in some cases. Accordingly, bench programming allows for a more convenient, controlled, and efficient flashing and diagnostics process.
What Do You Need To Reprogram on The Bench?
Whether on the bench or in-vehicle, reprogramming a BCM requires a few key components beyond the BCM itself.
- Bench Harness or Vehicle Harness/Adapter
- Stable Power Supply
- Programming Tool / Diagnostic Interface
- Interface Tools
Get Programming
BenchForce specializes in bench programming solutions for automotive ECUs. We design and manufacture products such as harnesses, adapters, and starter kits that allow you to power up and communicate with various ECUs such as the BCM, TCM, ECM, and other modules off-vehicle. This makes it easier to perform software updates, diagnostics, and repairs on the bench. Browse our store today to get started.
